The low-height bed for modern care

Libra

The Libra bed offers a maximum of choice and flexibility and can be customised to the smallest detail to meet every need of its residents and care staff. It offers people in need of care protection and comfort while promoting their mobility. Our optional Vario Safe system for tool-free attachment of the saftey sides, headboards and footboards contributes significantly to these advantages. The Libra partner double bed gives couples the choice to sleep together or separately.

Model facts

Large adjustment range
Safe working load of 225 kg
Many design options
Full-length, combinable or split safety side
Vario Safe or Easy Click system
The Libra partner double bed can be flexibly separated and put back together again

Model variants

Elegant and flexible

Libra – Standard

Large height adjustment range approx. 25 – 80 cm
Safe working load 225 kg
Four 50mm double castors for good mobility

For better room hygiene

Libra – Variante movo

Free access to the floor under the bed allows thorough cleaning
Four 50 mm double castors at the foot end, two 125 mm fixed castors at the head end
Optional 20 cm bed extension

The care double bed

Libra – partner

2 mattress bases, each 90 cm wide, with a safe working load of 225 kg
Backrest and leg rest individually adjustable
Height adjustments and mattress base tilting are always synchronous for both sides – so no risk of entrapment

Optimal mobility

Libra - floor access Plus variant

Free access to the floor and effortless manoeuvrability through eight 50 mm double castors
Optional 100 cm mattress base width
Choice of comfort or hygiene mattress base

All additional information at a glance

We are pleased to provide our informational materials for you to download.

Brochure Care Bed Libra (english)
pdf, 5 MB

By loading the video, you accept YouTube's privacy policy.

The advantages for you

MODULAR SYSTEM - With numerous safety sides, chassis, head and footboards and decors to choose from, the Libra meets every requirement and always retains its elegant, home-like character.

ALWAYS THE RIGHT HEIGHT - With its adjustment range of about 25 to 80 cm, the Libra protects residents from falls, lightens the workload of carers and, thanks to its 3-stop function, always stops at the ideal ergonomic height for the resident to get in and out of bed.

HOTEL COMFORT - The mattress base can be adjusted to a sitting position to make sleeping, reading or eating a pleasure.

Libra – Vario Safe — The split safety side can be combined with homelike panels.

With the Libra partner, couples can enjoy a new feeling of well-being in the care home.

Libra – headboard and footboard can be removed — The headboard and footboard can be removed effortlessly, which provides easier access to the resident, e.g. for foot ...

Libra – sitting position — The sitting position is ideal for meals or watching TV.

Libra - Design options for the head and footboards — Design options for the head and footboards with the Vario Safe system.

Flexible fall prevention with the Libra care bed safety sides — The optional combination of split and full-length safety sides makes it possible to provide customised fall prevention.

Libra – low-height bed — With its lowest position of approx. 25 cm, the Libra bed supports efficient fall prevention without restricting the ...

Vario Safe – height adjustment — If an object blocks the height adjustment of the bed, the safety sides remain in position in order to prevent damage.

Libra – movo variant — Take part in everyday life again with the movo variant.

Technical specifications

The following overview presents the technical data and equipment options for this model of bed. With a tailor-made configuration and visual design, and with suitable accessories, you can plan a bed that precisely matches your facility’s requirements and interior design. Your area sales manager will be happy to inform you about all the possibilities.

	Libra – Standard	Libra – Variante movo	Libra – partner	Libra - floor access Plus variant
Mattress base in cm (mattress dimensions) in cm	90 x 200, 100 x 200	90 x 200, 100 x 200	90 x 200	90 x 200, 80 x 200, 100 x 200
External dimensions in cm	104,0 x 209,4, 114,0 x 209,4	104,0 x 209,4, 114,0 x 209,4	ca. 195,6 x 209,4	104,0 x 209,4, 114,0 x 209,4
Bed extension in cm	10 / 20	10 / 20	20	10 / 20
Ground clearance in cm ca.	15	15	15	15
Safe working load in kg	225	225	225	225
Total weight in kg	135	135	135	135
Maximum weight of patient in kg ca.	185 - 210	185 - 210	185 - 210	185 - 210
Tilting to Trendelenburg position in °	12	12		12
Tilting to reverse-Trendelenburg position in °	12	12	12	12
Mattress base height in cm (from - to)	25 - 80	28 - 83	25 - 80	25 - 80
Backrest angle in °	70	70	70	70
Thigh rest angle in ° ca.	40	40	40	40
Auto contour adjustment / Fowler position
Manual CPR release of the backrest
Electrically adjustable
Drive system in V	230	230	230	230
24-volt drive concept with external transformer

* = Not available in all colors
= Standard
= Optional
= Not available

	Libra – Standard	Libra – Variante movo	Libra – partner	Libra - floor access Plus variant
Mattress base division in cm	72/25/33/54	72/25/33/54	72/25/33/54	72/25/33/54
Backrest length compensation	8	8	8	8
Metal slatted lying surface
Comfort mattress base
Comfort lying surface inserts
PP hygiene mattress base
4-section mattress base
Mattress base tiltable to reverse-Trendelenburg position
Mattress base tiltable to Trendelenburg position

* = Not available in all colors
= Standard
= Optional
= Not available

	Libra – Standard	Libra – Variante movo	Libra – partner	Libra - floor access Plus variant
No safety side
Protective height of safety sides	41	41	41	41
Full-length safety side attachable
Split safety side – combinable
split safety side – combinable – Vario-Safe-System

* = Not available in all colors
= Standard
= Optional
= Not available

	Libra – Standard	Libra – Variante movo	Libra – partner	Libra - floor access Plus variant
Double castor Ø 50 mm
Double castor Ø 100 mm
Castor braking, central
Castor braking, per axle

* = Not available in all colors
= Standard
= Optional
= Not available

	Libra – Standard	Libra – Variante movo	Libra – partner	Libra - floor access Plus variant
Argentum paint colour
Bella Noce Choco decor (R 30019 VV)
Beech Crenata decor (R 24096 VV)
Natural Beech decor (R 24010 VV)
Style Oak Cinnamon decor (R 20100 VV)
Precious Cherry decor (R 42002 VV)
Havana Cherry decor (R 42006 VV)
Royal Maple decor (R 27001 VV)
Chalk decor (U 11102 VV)
Lindberg Oak decor (R 20021 VV)
Magnolia decor (U 11509 VV)
Truffle Baron Elm decor (R 37003 VV)
Natural Wild Pear decor (R 41004 VV)
Alero
Camo
Comodo
Lito
Lito reha
Nobla
Nobla reha
Nobla mala
Pino
Podego
Prinzino
Solvo

* = Not available in all colors
= Standard
= Optional
= Not available

	Libra – Standard	Libra – Variante movo	Libra – partner	Libra - floor access Plus variant
Handset with selective locking function
Lead-gel battery
Under bed light
Integrated light connection
Additional handset for tilting the head end and foot end (Trendelenburg)

* = Not available in all colors
= Standard
= Optional
= Not available
