The classic hospital bed evolved

Seta pro

For years, Seta has embodied the high Stiegelmeyer standard for hospital beds. As Seta pro with an evolved chassis, it now meets even higher demands in terms of hygiene and design. A particular advantage lies in its sturdily integrated continuous safety sides.

Model facts

Individually configurable using an intelligent modular system
Continuous safety sides with edge protection ensure a long service life with low follow-on costs
Quick and easy cleaning

Model variants

The bed for a high level of safety

Seta pro - Standard

Mattress base 90 x 200 cm
Height adjustment range of 32 - 91 cm, depending on castor
Continuous safety sides anchored firmly in head and footboards

Low-height and high stability

Seta pro - brevo variant

Height adjustment range from a low-level 28 to 84 cm
Fall prevention without the use of deprivation of liberty safeguards

The narrow low-height bed

Seta pro - brevo lino variant

Combines the narrow overall dimensions and extensive adjustment range of the lino and brevo variants

Narrow and manoeuvrable

Seta pro - lino variant 87 cm

Mattress base 87 x 200 cm
External dimensions only 99.5 x 214.5 cm for easy manoeuvring
Ideal for small rooms and narrow corridors

The narrow bed

Seta pro - lino variant 80 cm

Mattress base 80 x 200 cm
External dimensions only 92,8 x 219,3 cm for easy manoeuvring
Ideal for small rooms and narrow corridors

All additional information at a glance

We are pleased to provide our informational materials for you to download.

Brochure hospital bed Seta pro (english)
pdf, 2 MB

Advantages

SAFETY - The Seta pro's standard full-length safety side provides maximum protection for patients at risk of falling. It is firmly integrated into the head and footboards and is therefore particularly sturdy.

EASY OPERATION - The Seta pro can be operated safely using an intuitive handset. The electronic components are easily accessible for maintenance and inspection.

HYGIENE - The optional automated reprocessing ensures particularly safe, validatable hygiene.

Diagonally raised full-length safety side on the Seta pro hospital bed — Patients enjoy better spatial orientation when safety side bars are raised diagonally.

Optional control box on the Seta pro hospital bed — The optional control box combines all the Seta pro’s control options on a generous surface area.

Extension of the lower leg rest on the Seta pro hospital bed — The lower leg rest extension moves with the leg rest when adjustments are made to the Seta pro.

Concealed cable routing on the Seta pro hospital bed — The Seta pro’s concealed cable routing ensures smooth surfaces that are easy to clean.

Good hygiene properties of the Seta pro hospital bed — All structural parts of the Seta pro are easily accessible for thorough cleaning.

Hygiene mattress base of the Seta pro hospital bed — The polypropylene hygiene mattress base consists of removable sections that can be separately removed and are designed ...

Pull-out safety side bars on the Seta pro hospital bed — When using the bed extension, the safety side bars can also be extended.

The HPL mattress base of the Seta pro hospital bed — The all-plastic mattress base consists of 4 HPL elements with cut-outs to allow healthy circulation of the air.

The easily accessible control of the Seta pro hospital bed — The electronic components of the Seta pro are easily accessible under the backrest.

Removable head and footboard of the Seta pro hospital bed — For beds fitted with MultiFlex safety sides, the entire head and footboard can be removed if desired.

Wall deflection roller and buffer cone on the Seta pro hospital bed — Wall deflection rollers and buffer cones protect the Seta pro from damage due to horizontal and vertical collisions.

Wall deflection rollers and wall buffer cones on the Seta pro hospital bed with MultiFlex safety sides — Wall deflection rollers and wall buffer cones are also standard features with the MultiFlex split safety side.

Sturdy full-length safety side on the Seta pro hospital bed — Only the Seta pro offers the advantage of a full-length safety side that is integrated directly in the head and ...

Technical data

The following overview presents the technical data and equipment options for this model of bed. With a tailor-made configuration and visual design, and with suitable accessories, you can plan a bed that precisely matches your hospital’s requirements and interior design. Your area sales manager will be happy to inform you about all the possibilities.

	Seta pro - Standard	Seta pro - brevo variant	Seta pro - brevo lino variant	Seta pro - lino variant 87 cm	Seta pro - lino variant 80 cm
Mattress base in cm (mattress dimensions) in cm	90 x 200	90 x 200	87 x 200	87 x 200	80 x 200
External dimensions in cm	103,8 x 219,3	103,8 x 219,3	99,8 x 219,3	99,8 x 219,3	92,8 x 219,3
Bed extension in cm	22.5	22.5	22.5	22.5	22.5
Ground clearance in cm ca.	16.9 (14.1 for Ø150 Linea)	14,3	14,3	16.9 (14.1 for Ø150 Linea)	16.9 (14.1 for Ø150 Linea)
Safe working load in kg	260	260	260	260	260
Total weight in kg	155	155	155	155	155
Maximum weight of patient in kg ca.	250	250	250	250	250
Tilting to Trendelenburg position in °	17	17	17	17	17
Tilting to reverse-Trendelenburg position in °	17	16	16	17	17
Mattress base height in cm (from - to)	35 - 91 (32-88 bei Ø150 Linea)	28 - 84	28 - 84	35 - 91 (32-88 bei Ø150 Linea)	35 - 91 (32-88 bei Ø150 Linea)
Backrest angle in °	70	70	70	70	70
Thigh rest angle in ° ca.	40	40	40	40	40
Auto contour adjustment / Fowler position
Manual CPR release of the backrest
Electrically adjustable

* = Not available in all colors
= Standard
= Optional
= Not available

	Seta pro - Standard	Seta pro - brevo variant	Seta pro - brevo lino variant	Seta pro - lino variant 87 cm	Seta pro - lino variant 80 cm
Mattress base division in cm	83/15/33/54	83/15/33/54	83/15/33/54	83/15/33/54	83/15/33/54
Backrest length compensation	10	10	10	10	10
PP hygiene mattress base
PP hygiene mattress base for belt system
Full plastic (HPL) hygiene mattress base for belt system
Wire mesh base (removable)
Wire mesh base (fixed)
4-section mattress base

* = Not available in all colors
= Standard
= Optional
= Not available

	Seta pro - Standard	Seta pro - brevo variant	Seta pro - brevo lino variant	Seta pro - lino variant 87 cm	Seta pro - lino variant 80 cm
Protective height of safety sides	41	41	41	41	41
Full-length safety side attachable

* = Not available in all colors
= Standard
= Optional
= Not available

	Seta pro - Standard	Seta pro - brevo variant	Seta pro - brevo lino variant	Seta pro - lino variant 87 cm	Seta pro - lino variant 80 cm
Integral castor Ø 150 mm
Double castor Ø 150 mm
5th castor (double castor Ø 125 mm)
Castor braking, central
Linea double castor Ø125 mm
Linea double castor Ø150 mm

* = Not available in all colors
= Standard
= Optional
= Not available

	Seta pro - Standard	Seta pro - brevo variant	Seta pro - brevo lino variant	Seta pro - lino variant 87 cm	Seta pro - lino variant 80 cm
Argentum paint colour
Crystal paint colour
Azur decor (0744-60)
Baltic Sea decor (0475-60)
Eternal Cherry decor (4325-60)
Global Beech decor (4306-60)
Gold decor (0446-60)
Noce Lyon decor (4232-60)
Noce Praliné decor (4452-60)
Ottawa Maple decor (4209-60)
Silver Grey decor (0160-60)
Snow White decor (9417-60)
Storm decor (10542-60)
Valley Oak decor (4166-60)
Headboard and footboard completely removable
Base

* = Not available in all colors
= Standard
= Optional
= Not available

	Seta pro - Standard	Seta pro - brevo variant	Seta pro - brevo lino variant	Seta pro - lino variant 87 cm	Seta pro - lino variant 80 cm
Standard handset
LCD handset
Control satellite
Locking box in the linen holder
Control box in the linen holder
Foot pedal
Lead-gel battery
Lithium-ion battery
Under bed light
Out-of-Bed system
Brake signal
Angle indicator

* = Not available in all colors
= Standard
= Optional
= Not available
