Sicuro tera

The bed for demanding intensive care

In the intensive care unit, every move has to be right, every procedural step has to follow on seamlessly from the previous one. Stiegelmeyer spoke with the people who bear great responsibility every day in this aspect. Their wishes and requirements have led to a new intensive care bed that supports their hard work in every situation. Discover our Sicuro tera, the intelligent bed for more relief and efficiency.

Model facts

  • lateral tilting
  • many mounting possibilities for accessories
  • optional integrated scales
  • machine washable
  • safe working load of 260 kg


Advantages for you

Patient anamnesis

Weighing the patient – the easy and reliable way

[Translate to International (Englisch):]
  • the scales of the Sicuro tera measure accurately to 200 grams
  • the patient's weight influences the optimal dosage of medication
  • with a safe working load of 260 kg, patients up to 250 kg can be placed in the bed


Mounting options

for medical equipment

[Translate to International (Englisch):]
  • Sicuro tera has standard rails all around
  • additional rails can be attached to the safety sides
  •  the stainless-steel tubes of the head and footboards can also be used for mounting

Medical positioning

Relief through lateral tilting

[Translate to International (Englisch):]
  • lateral tilting for improved oxygen supply
  • all important care positions can be set at the touch of a button on the control panel
  • all adjustments are also possible at the max. patient weight

Relieving the strain on nursing staff

Reduce effort in everyday life

[Translate to International (Englisch):]
  • the foot pedal and lateral tilting support the care staff during their work
  • the fifth  castor helps transport patient to examinations
  • the safety side can be raised and lowered effortlessly using just one hand
Technical specifications
Technical specificationsContact
ContactDownloads
Downloads

Your advantages

Mounting possibilities for medical devices

The Sicuro tera has standard rails around almost all load-bearing construction elements. This way, mounting the required equipment is no longer a problem. In addition, standard rails can also be attached to the safety sides.

Several accessories from Stiegelmeyer support you in mounting medical equipment.


The emergency position can be set in seconds via the integrated control.
If necessary, the integrated bed extension provides more space.
The sitting position makes it easier to eat meals and converse with other people at eye level.
The backrest can be lowered quickly with the emergency lowering lever.
The bed is easy to clean both manually and mechanically.
The side recesses of the mattress base can be used to attach belt systems.
Head-side access to the patient is established within seconds.
Im Notfall kann durch den einfachen Mechanismus das Kopfteil entriegelt werden.
With the help of the foot pedals, the bed can be adjusted without touching it near the patient.
The lateral tilt supports easy patient mobilisation.
The Protega safety side can be raised and lowered effortlessly using just one hand.
Rails can be attached to the safety sides if desired.
Thanks to the radiolucent backrest, the patient does not have to be moved in a time-consuming manner during X-rays.
Patients can move the bed into a comfortable position with the optional LCD handset.
The optional fifth castor supports the good manoeuvrability of the bed.
Weight is often decisive in the patient's medical history. The scale measures to the nearest 200 grams.
The emergency position can be set in seconds via the integrated control.
If necessary, the integrated bed extension provides more space.
The sitting position makes it easier to eat meals and converse with other people at eye level.
The backrest can be lowered quickly with the emergency lowering lever.
The side recesses of the mattress base can be used to attach belt systems.
The bed is easy to clean both manually and mechanically.
Head-side access to the patient is established within seconds.
Im Notfall kann durch den einfachen Mechanismus das Kopfteil entriegelt werden.
With the help of the foot pedals, the bed can be adjusted without touching it near the patient.
The Protega safety side can be raised and lowered effortlessly using just one hand.
The lateral tilt supports easy patient mobilisation.
Rails can be attached to the safety sides if desired.
Thanks to the radiolucent backrest, the patient does not have to be moved in a time-consuming manner during X-rays.
Patients can move the bed into a comfortable position with the optional LCD handset.
The optional fifth castor supports the good manoeuvrability of the bed.
Weight is often decisive in the patient's medical history. The scale measures to the nearest 200 grams.

Technical specifications

The following overview presents the technical data and equipment options for this model of bed. With a tailor-made configuration and visual design, and with suitable accessories, you can plan a bed that precisely matches your requirements and your interior design. Your area sales manager will be pleased to inform you about all the options.

Sicuro teraSicuro tera mit WaageSicuro tera extra langSicuro tera extra lang mit Waage
Mattress base in cm (mattress dimensions) in cm 90 x 200 90 x 200 90 x 210 90 x 210
External dimensions in cm 103,8 x 218,6 103,8 x 218,6 103,8 x 226,6 103,8 x 226,6
Bed extension in cm 28 28 18 18
Safe working load in kg 260 260 260 260
Ground clearance of chassis in cm 6 6 6 6
Total weight in kg 208 208 218 218
Maximum weight of patient in kg 250 250 250 250
Tilting to Trendelenburg position in ° 16 16 16 16
Tilting to reverse-Trendelenburg position in ° 18 18 18 18
Lateral tilting in ° 25 25 25 25
Mattress base height in cm (from - to) 45 – 84 45 – 84 45 – 84 45 – 84
Backrest angle in ° 70 70 70 70
Thigh rest angle in ° 40 40 40 40
  • = Standard
  • = Optional
  • = Not available
Sicuro teraSicuro tera mit WaageSicuro tera extra langSicuro tera extra lang mit Waage
Mattress base division in cm 83-15-33-53 83-15-33-53 83–15–33–61 83–15–33–61
Backrest length compensation 10 10 10 10
PP hygiene mattress base
PP hygiene mattress base for belt system
PP hygiene mattress base for belt system with radiolucent backrest
  • = Standard
  • = Optional
  • = Not available
Sicuro teraSicuro tera mit WaageSicuro tera extra langSicuro tera extra lang mit Waage
Protective height of safety sides 40 40 40 40
Protega
  • = Standard
  • = Optional
  • = Not available
Sicuro teraSicuro tera mit WaageSicuro tera extra langSicuro tera extra lang mit Waage
5th castor (double castor Ø 125 mm)
Conductive castor coating: 1 castor
Conductive castor coating: 2 castors
Conductive castor coating: 4 castors
4 wall deflection rollers, plastic, all sides
Wall deflection rollers: 2 universal at head end, 2 plastic at foot end
Brake pedal: 2 x die-cast, chrome-plated with coloured marking
Brake pedal: 4 x die-cast, chrome-plated with coloured marking
Directional castor position: head end, right
Directional castor position: foot end, left
Foot end, left (directional castor position)
Directional castor position: foot end, right
Directional castor position: Brake centre (fifth castor)
  • = Standard
  • = Optional
  • = Not available
Sicuro teraSicuro tera mit WaageSicuro tera extra langSicuro tera extra lang mit Waage
Rondo
Stelo
Base colour Crystal white NCS S0500N
Automated reprocessing, IPX6W
  • = Standard
  • = Optional
  • = Not available
Sicuro teraSicuro tera mit WaageSicuro tera extra langSicuro tera extra lang mit Waage
Integrated control panel
Integrated control panel + control box + 1 LCD handset
Integrated control panel + control box + 2 LCD handsets
Foot switches with two adjustment functions
Lithium-ion battery
Under bed light
Out-of-Bed system
Brake signal
Standard sliding rail at foot end
6 standard sliding rails at the sides and 1 at the head end
Standard sliding rails on backrests
Linen holder
Lower leg rest extension
Bed extension
Adapter sleeve for patient lifting pole, oval tube
Adapter sleeve for patient lifting pole, round tube
Angle indicator
  • = Standard
  • = Optional
  • = Not available

Do you have any questions regarding Sicuro tera?

You can find further information in the download section, or you can contact us directly.
