More than just a bed

Puro

The Puro hospital bed provides a new quality of life in everyday hospital life with safety, comfort and elegance. The Puro sets high standards in terms of hygiene, ease of operation and individual comfort. It promotes recovery and facilitates the work of many hospital units.

Model facts

Safe working load 250-275 kg
Maximum weight of patient approx. 230-260 kg
28 cm bed extension
Encourages mobility with MultiFlex⁺ safety side

Advantages for you

The flexible bed

Puro – standard variant

Safe working load of up to 275 kg
Wide range of optional features for intensive care units and psychiatric care
Machine-washable option
Also available in the slimline lino variant

The low-height bed

Puro – brevo variant

Safe working load of up to 275 kg
Ideal for meeting the special needs of geriatric and dementia patients
Machine-washable option
Also available in the slimline lino variant

The budget-oriented bed

Puro - econ variant

Height adjustment of 32 - 91 cm (depending on castors)
Safe working load of 250 kg
Flat surface design and protection category IPX4 to promote thorough manual reprocessing
Safe and long-life lead-acid battery
Sturdy plastic brake pedals with coloured markings
Also available in the slimline lino variant

All additional information at a glance

We are pleased to provide our informational materials for you to download.

Brochure hospital bed Puro (english)
pdf, 3 MB

The advantages for you

HYGIENE – Beds play an important role in the fight against multi-resistant pathogens. The Puro is very easy to clean with its low-niche design. The optional machine-washable version sets particularly high hygiene standards.

OPERATION – the LCD handset controls the bed with just 3 buttons and offers tailor-made control levels for patients, nurses and technical staff.

SAFETY – the split MultiFlex⁺ safety side is quiet and easy to operate and offers an ideal balance between protection and freedom.

► Instruction videos of the functions of the Puro hospital bed

Universal wall deflection roller on the Puro hospital bed — The universal wall deflection roller affords vertical and horizontal protection during adjustments of the Puro.

A nurse helping a patient get up with the aid of the Puro’s height adjustment and mobilisation support — The Puro is always at the ideal height and supports nurses when they mobilise patients.

The Puro hospital bed promotes patient mobilisation — The Puro’s large height adjustment range and mobilisation support make it easier for patients to stand up.

A patient uses the mobilisation support on the Puro hospital bed to stand up — The mobilisation support for the Puro MultiFlex+ safety side is easy to raise.

Puro low-height bed – brevo variant — The low-height brevo variant of the Puro promotes fall prevention.

Puro hospital bed in the cardiac chair position — The Puro uses the reverse-Trendelenburg position and mattress base adjustment to provide a cardiac chair position.

Time-saving inspection of the electronic components of the Puro hospital bed — The Puro’s control and rechargeable battery are very easy for technicians to reach.

The LCD handset of the Puro hospital bed indicates the preset backrest angle — The LCD handset indicates when the backrest reaches 15°, 30°, 45°, 60° or the maximum angle.

Any spaces incorporated in the Puro hospital bed are easy to clean — Even the necessary spaces incorporated in the Puro are designed to be large enough to allow easy access for cleaning.

Handset holder on the mobilisation support of the Puro hospital bed — The LCD handset is always within easy reach in a holder on the mobilisation support.

Easy to clean thanks to concealed cable routing on the Puro hospital bed — The concealed cable routing in the Puro bed frame prevents the creation of spaces where dirt could accumulate.

Wall buffer cones and deflection rollers are included as standard on the Puro hospital bed — Wall buffer cones and deflection rollers are standard features that protect the Puro from collision damage.

Slimline Puro lino variant for easy manoeuvrability — The lino variant (left) is 4 cm narrower than the Puro Standard (right) and is easier to manoeuvre.

The Puro’s electronic components are easy to access for maintenance and inspection — All electronic components of the Puro are easy to reach, allowing service technicians to save up to 20 minutes’ time.

Unlocking magnet for changing between control levels on the LCD handset of the Puro hospital bed — Changing between control levels on the LCD handset is quick and easy using the unlocking magnet on the Puro.

28 cm bed extension on the Puro hospital bed — The 28 cm bed extension supplied as standard with the Puro is effortless to unfasten and remove.

Release mechanisms for removing the Puro’s head and footboard — The release mechanisms for the Puro’s removable head and footboard are easy to reach and operate.

The handle bar on the Puro hospital bed is easy to clean — All components are built for ease of cleaning - including the handle bar of the Rondo head and footboard.

Holder for the LCD handset on the Puro hospital bed — The LCD handset is in a safe, protected transport position on the Puro while the bed is being moved.

Removable head and footboard on the Puro hospital bed — The Puro’s head and footboard can be released and removed in seconds to provide better access to the patient.

Control box in the linen holder of the Puro hospital bed — Adjustment functions can be conveniently managed with the optional control box in the Puro’s linen holder.

Under bed light for orientation at night on the Puro hospital bed — The under bed light helps with orientation. It is activated on the LCD handset or the Out-of-Bed system.

Large-surface chassis of the Puro hospital bed — Just as the entire bed, the Puro’s chassis impresses with its large-surface, hygiene-friendly design.

Optional fifth castor on the Puro hospital bed — The optional fifth castor helps to make the Puro even easier to manoeuvre. It is always the directional castor as well.

Technical specifications

The following overview presents the technical data and equipment options for this model of bed. With a tailor-made configuration and visual design, and with suitable accessories, you can plan a bed that precisely matches your hospital’s requirements and interior design. Your area sales manager will be happy to inform you about all the possibilities.

	Puro standard variant	Puro – standard lino variant	Puro – brevo variant	Puro – brevo lino variant	Puro - econ variant	Puro - econ lino variant
Mattress base in cm (mattress dimensions) in cm	90 x 200	87 x 200	90 x 200	87 x 200	90 x 200	87 x 200
External dimensions in cm	103,5 x 218,5	99,5 x 214,5	103,5 x 218,5	99,5 x 214,5	103,5 x 218,5	99,5 x 214,5
Bed extension in cm	28	28	28	28	28	28
Safe working load in kg	275	275	275	275	250	250
Ground clearance of chassis in cm	16,9	16,9	14,3	14,3	16,9	16,9
Ground clearance of chassis with Linea castor Ø 150mm	14,1	14,1	16,8	16,8	14,1	14,1
Total weight in kg	155	155	155	155	155	155
Maximum weight of patient in kg ca.	250	250	250	250	210 - 240	210 - 240
Tilting to Trendelenburg position in °	17	17	17	17	17	17
Tilting to reverse-Trendelenburg position in °	17	17	16	16	17	17
Mattress base height in cm (from - to)	35 - 91	35 - 91	28 - 84	28 - 84	35 - 91	35 – 91
Mattress base height with Linea Ø 150mm	ca. 32-88 cm	ca. 32-88 cm	ca. 30-86 cm	ca. 30-86 cm	ca. 32-88 cm	ca. 32-88 cm
Backrest angle in °	70	70	70	70	70	70
Thigh rest angle in ° ca.	40	40	40	40	40	40
Fowler position angle	16	16	16	16	16	16
Auto contour adjustment / Fowler position
Manual CPR release of the backrest
Electrically adjustable

* = Not available in all colors
= Standard
= Optional
= Not available

	Puro standard variant	Puro – standard lino variant	Puro – brevo variant	Puro – brevo lino variant	Puro - econ variant	Puro - econ lino variant
Mattress base division in cm	ca. 83/15/33/53	ca. 83/15/33/53	ca. 83/15/33/53	ca. 83/15/33/53	ca. 83/15/33/ 53	ca. 83/15/33/53
Backrest length compensation	10	10	10	10	10	10
PP hygiene mattress base
PP hygiene mattress base for belt system
Full plastic (HPL) hygiene mattress base for belt system
Wire mesh base (removable)
Wire mesh base (fixed)
Adjustable standard
Depth-adjustable

* = Not available in all colors
= Standard
= Optional
= Not available

	Puro standard variant	Puro – standard lino variant	Puro – brevo variant	Puro – brevo lino variant	Puro - econ variant	Puro - econ lino variant
Protective height of safety sides	42	42	42	42	42	42
Full-length safety side attachable
MultiFlex split safety side

* = Not available in all colors
= Standard
= Optional
= Not available

	Puro standard variant	Puro – standard lino variant	Puro – brevo variant	Puro – brevo lino variant	Puro - econ variant	Puro - econ lino variant
Integral castor Ø 150 mm
5th castor (double castor Ø 125 mm)
Castor braking, central
Conductive castor coating: 1 castor
Conductive castor coating: 2 castors
Conductive castor coating: 4 castors
5 castors, (conductive castor coating)
Linea double castor Ø150 mm
Steinco double castor Ø 150 mm
4 wall deflection rollers, plastic, all sides
4 wall deflection rollers, universal, all sides
Wall deflection rollers: 2 universal at head end, 2 plastic at foot end
2 x plastic with coloured marking (brake pedal)
Brake pedal: 2 x die-cast, chrome-plated with coloured marking
Brake pedal: 4 x die-cast, chrome-plated with coloured marking
Directional castor position: head end, right
Directional castor position: head end, left
Directional castor position: foot end, left
Directional castor position: foot end, right
Head and foot end (wall buffer cone)
Directional castor position: Brake centre (fifth castor)

* = Not available in all colors
= Standard
= Optional
= Not available

	Puro standard variant	Puro – standard lino variant	Puro – brevo variant	Puro – brevo lino variant	Puro - econ variant	Puro - econ lino variant
Argentum paint colour
Crystal white paint colour
Azur decor (0744-60)
Baltic Sea decor (0475-60)
Eternal Cherry decor (4325-60)
Global Beech decor (4306-60)
Gold decor (0446-60)
Noce Lyon decor (4232-60)
Noce Praliné decor (4452-60)
Ottawa Maple decor (4209-60)
Silver Grey decor (0160-60)
Snow White decor (9417-60)
Storm decor (10542-60)
Valley Oak decor (4166-60)
Rondo - Design head and footboards
Stelo - Design head and footboards
Base colour Crystal white NCS S0500N
Headboard and footboard completely removable
Manual reprocessing, IPX6
Automated reprocessing, IPX6W
Intercontinental - Design head and footboards*
Manual reprocessing, IPX4

* = Not available in all colors
= Standard
= Optional
= Not available

	Puro standard variant	Puro – standard lino variant	Puro – brevo variant	Puro – brevo lino variant	Puro - econ variant	Puro - econ lino variant
Lithium-ion battery
Under bed light
Out-of-Bed system
Brake signal
Linen holder
Lower leg rest extension
Bed extension
Standard handset
LCD handset
2 LCD handsets
Control satellite
Locking box in the linen holder
Control box in the linen holder
Foot pedal
Lead-gel battery
Out-of-Bed system, including under bed light
Backrest angle indicator on LCD handset
Standard sliding rail at head end
Standard sliding rails along the side under backrest

* = Not available in all colors
= Standard
= Optional
= Not available

Puro

Model facts
